Products >> TRICYCLE >> H SERIES
| BRAND NAME | NVP MOTO |
| MODEL NAME | NVP200ZH-H1 |
| DIMENSION(L*W*H) | 3250MM*1300MM*1350MM |
| MINIMUM GROUND CLEARANCE | 230MM |
| NET WEIGHT | 430KG |
| MAX LOADING WEIGHT | 1400KG |
| MAX SPEED | 90KM/H |
| REAR CARGO BOX | 1.25 M(WIDTH)*2.0 M(LENGTH) |
| FRONT BRAKE SYSTEM | DRUM BRAKE |
| REAR BRAKE SYSTEM | DRUM BRAKE |
| LEAF SPRING | HEAVY DUTY, 16KG ONE PIECE |
| FRONT SHOCK ABORBER | 50MM DIAMETER STYLE |
| FRONT TIRE | 5.00-12 |
| REAR TIRE | 5.00-12 |
| FUEL TANK CAPACITY | 19 LITERS |
| ENGINE POWER | 200CC |
| ENGINE TYPE | SINGLE CYLINDER,4 STROKES, WATER COOLED |
| STARTING SYSTEM | KICK/ELECTRIC |
| IGNITION MODE | C.D.I |
| OIL CONSUMPTION | 2.3L/100KM |
| GEAR WAY | 5 GEARS |
| CONTAINER LOADING QUANTITY | 42 UNITS/CKD |
| AVAILABLE COLOR |       |
Next Product：NVP200ZH-H2
